<h3>Application</h3>

<p>(48) circuits of &nbsp;either 120 VAC or 208 VAC make an ideal distribution for entertainment lighting.</p>

<h4>Specifications</h4>

<ul>
	<li><strong>Input:</strong>&nbsp;(5) 16 Series Cam-type panel mount Male devices, straight</li>
	<li><strong>Thru:</strong>&nbsp;(5) 16 Series Cam-type panel mount Female devices with protective covers, straight</li>
	<li><strong>Main Breaker:</strong>&nbsp;400 Amp</li>
	<li><strong>Output:</strong>&nbsp;(8) 6-circuit, 120V LSC19 receptacles and (8) 6-circuit, 208V LSC19 receptacles (parallel)</li>
	<li>(6) NEMA L21-30, 30 Amp locking receptacles</li>
	<li>(6) NEMA 5-20, 20 Amp duplex receptacles</li>
	<li><strong>Overcurrent Protection:</strong>&nbsp;(48) 20 Amp, 2 Pole branch rated circuit breakers</li>
	<li>(6) 30 Amp, 3 Pole branch rated circuit breakers</li>
	<li>(6) 20 Amp, Single Pole branch rated circuit breakers</li>
	<li><strong>Dimensions:</strong>&nbsp;26&quot; L x 24&quot; W x 39-1/2&quot; H</li>
</ul>

<h4>Features &amp; Benefits</h4>

<ul>
	<li>Extruded aluminum frames combined with high density polyethylene (HDPE) enclosure panels create lightweight yet remarkably strong and extremely durable rack enclosures</li>
	<li>Front and back rack doors have &quot;snap-in&quot; latches for ease of access</li>
	<li>All rack hardware is recessed on HDPE panels to protect from breakage and there are no exposed latches when doors are removed</li>
	<li>All 19&quot; rack panels are laser engraved for clear and concise identification</li>
	<li>100% rated, electronic main and magnetic branch circuit breakers eliminates worry of thermal tripping</li>
	<li>LED power indicators, including discrete six (6) circuit arrays for multipin receptacles, provide clear live circuit identification</li>
</ul>


Rent the Lex 48 208V power distro with 48 circuits, 400A main breaker, LSC19 and NEMA outlets, LED indicators, and a durable, lightweight build.

Buy a Lex 48 208V power distro with 48 circuits, 400A main breaker, LSC19 and NEMA outlets, LED indicators, and a durable, lightweight build.

Rent the Lex 48 208v Presidential Power Rack

Purchase the Lex 48 208v Presidential Power Rack

Lex 48 Circuit 120v/208v Presidential Power Rack

LEX48120208V

Once your rental quote is requested, a representative will contact you to discuss availability, pricing, shipping method and costs.
